American Power Design高壓DC/DC轉換器產品介紹

發布時間：2025-05-06 09:43:29     瀏覽：104

　　美國電源設計公司(American Power Design, Inc.)是一家專注于高壓直流/直流轉換器(High Voltage DC/DC Converters)的制造商，其產品廣泛應用于需要高電壓輸出的電子設備和系統中。這些轉換器以其高性能、高可靠性和靈活的輸入輸出電壓范圍而受到市場的青睞。

American Power Design高壓DC/DC轉換器產品介紹

　　應用領域

　　American Power Design 的高壓直流/直流轉換器廣泛應用于以下領域：

　　工業設備：用于高電壓驅動設備、工業自動化系統等。

　　科研儀器：適用于實驗室設備、高精度儀器等需要高電壓輸出的場景。

　　醫療設備：用于需要高電壓電源的醫療成像設備等。

　　航空航天：為航空航天設備提供高可靠性、高電壓的電源解決方案。

　　產品系列

系列輸出功率輸出電壓輸入電壓范圍
A55.0 W24Vdc to 200Vdc9-36Vdc, 20-60Vdc, 36-72Vdc
A1515.0 W24Vdc to 200Vdc9-36Vdc, 20-60Vdc, 36-72Vdc
A5050.0 W24Vdc to 200Vdc10-20Vdc, 18-36Vdc, 36-72Vdc
A100100.0 W48Vdc to 200Vdc10-20Vdc, 18-36Vdc, 36-72Vdc
C7575.0 W3Vdc to 28Vdc10-20Vdc, 18-36Vdc, 20-60Vdc, 36-72Vdc
D150150.0 W3Vdc to 28Vdc10-20Vdc, 18-36Vdc, 20-60Vdc, 36-72Vdc
E11.0 W-8000Vdc to 8000Vdc11.5V-16Vdc
E33.0 W-8000Vdc to 8000Vdc11.5V-16Vdc
F11.0 W-2000Vdc to 2000Vdc5Vdc, 12Vdc
G1010.0 W-20000Vdc to 20000Vdc22.8V-28.8Vdc
H1010.0 W24Vdc to 1000Vdc5-15Vdc, 9-36Vdc, 20-60Vdc
H3030.0 W24Vdc to 1000Vdc9-36Vdc, 20-60Vdc
H5050.0 W24Vdc to 1000Vdc9-36Vdc, 20-60Vdc
H150150.0 W24Vdc to 1000Vdc18-36Vdc, 20-60Vdc
J050.5 W-2000Vdc to 2000Vdc0V-5Vdc, 0V-12Vdc, 0V-24Vdc
J33.0 W-6000Vdc to 6000Vdc0V-5Vdc, 0V-12Vdc, 0V-24Vdc
J55.0 W-3000Vdc to 6000Vdc0V-12Vdc
J1010.0 W-3000Vdc to 6000Vdc0V-12Vdc , 0V-15Vdc
K1010.0 W-4000Vdc to 4000Vdc0V-12Vdc, 0V-15Vdc, 0V-24Vdc, 0V-28Vdc
L11.0 W24Vdc to 500Vdc5Vdc, 12Vdc, 24Vdc, 48Vdc
L33.0 W24Vdc to 500Vdc5Vdc, 12Vdc, 24Vdc, 48Vdc
M55.0 W24Vdc to 1000Vdc10-20Vdc, 18-36Vdc
M1010.0 W24Vdc to 1000Vdc10-20Vdc, 18-36Vdc
M3030.0 W48Vdc to 1000Vdc10-20Vdc, 18-36Vdc
P11.0 W-3000Vdc to 6000Vdc0-12Vdc
P22.0 W-3000Vdc to 6000Vdc0-12Vdc
P33.0 W-3000Vdc to 12000Vdc0-12Vdc, 0-15Vdc
P1010.0 W100Vdc to 8000Vdc4-12Vdc
Q22.0 W-5000Vdc to 5000Vdc24V-30Vdc
Q44.0 W-5000Vdc to 5000Vdc24V-30Vdc
S11.0 W50Vdc to 500Vdc9-36Vdc
S33.0 W50Vdc to 500Vdc9-36Vdc
S55.0 W24Vdc to 1000Vdc9-36Vdc, 20-60Vdc, 36-72Vdc
S1010.0 W24Vdc to 1000Vdc9-36Vdc, 20-60Vdc, 36-72Vdc
S2020.0 W24Vdc to 1000Vdc9-36Vdc, 20-60Vdc, 36-72Vdc
S3030.0 W24Vdc to 1000Vdc9-36Vdc, 20-60Vdc, 36-72Vdc
X1010.0 W24Vdc to 1000Vdc9-36Vdc, 20-60Vdc, 36-72Vdc
X3030.0 W24Vdc to 1000Vdc9-36Vdc, 20-60Vdc, 36-72Vdc
X5050.0 W48Vdc to 1000Vdc9-36Vdc, 20-60Vdc, 36-72Vdc
X150150.0 W48Vdc to 1000Vdc18-36Vdc, 20-60Vdc, 36-72Vdc

深圳市立維創展科技有限公司優勢代理銷售American Power Design(APD)高壓DC/DC轉換器產品，歡迎咨詢了解。
